Creating Sounds and Effects
4-21
Be sure to check out presets 17, 41, 42, and 53-127 for examples of how to use
General Purpose patches. Here are some additional patching examples to try
out:
• Use the Chorus Delay algorithm.
• LFO control of ChorRat controls the depth and rate of the chorus effect.
• Threshold set to 64 “centers” the control range of the LFO.
• Scaling of 75% limits change of ChorRat between 1 and 12.
• You can use Mod Wheel, Velocity,Input Level or any other controller as a
Source instead of LFO. (Leave all other settings the same.)
Parameter Settings
LFO Rat ChorRat - - -
0.51Hz 7 - - -
Patch Settings
Src 1 Thresh1 Dest 1 Scale 1 Offset 1
LFO 64 ChorRat 75% -
• Use with any algorithm. Dry Pan settings will pan the unchanged input signal.
Wet pan setting will pan the processed output signal.
• Dry Pan “moves” a mono input signal between the left and right outputs. With
stereo input signals, Dry Pan inverts the left and right signal levels.
• Threshold set to 66 “centers” panning in the middle of a standard 5-octave
keyboard (F# above middle C).
• 199% scale value allows full range control of the parameter from a 61-note
keyboard
• Positive (R) scaling makes panning go from left to right as notes are played
from low to high. Negative (L) scaling pans from right to left when notes are
played low to high.
Parameter Settings
InLevl Mix Wet Pan Dry Pan OutLevl
100% 0% Center Center 100%
Patch Settings
Src 1 Thresh1 Dest 1 Scale 1 Offset 1
LastNot 66 Dry Pan 199%R -
Src 2 Thresh2 Dest 2 Scale 2 Offset 2
LastNot 66 Wet Pan 199%L -
Patching Examples
LFO Controlled Chorus
Keyboard Cross-Pan
