Lexicon LXP-15 - SysEx Data Formats

MIDI Implementation Data
7-3
Small Parameter Adjust
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 06 LXP-15 ID
3 0010 nnnn(bin) n = MIDI Channel 0-15
4 0ppp pppp p = parameter number 0 - 127
5 0vvv vvvv 7-bit data
6 F7 (hex) End of SysEx message
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 06 LXP-15 ID
3 0101 nnnn(bin) n = MIDI Channel 0-15
4 0ppp pppp p = parameter number 0 - 127
5 0vvv vvvv 7-bit data (lsb)
6 0vvv vvvv 7-bit data (msb)
7 F7 (hex) End of SysEx message
Byte Value Description
0 F0 (hex) System Exclusive
1 06 Lexicon ID
2 06 LXP-15 ID
3 0100 nnnn(bin) n = MIDI Channel 0-15
4 43 (hi) (hex) data byte count
5 00 (lo) (8576 = 0x2180 = 0x4280 in 7-bit)
6 0vvv vvvv(bin) 7-bit data
.
8581 0vvv vvvv
8582 0sss ssss sumcheck of data bytes
8583 F7 (hex) End of SysEx message
Big Parameter Adjust
All User Data
