6-3
MIDI Operation
Two LXP-15s can be slaved together by connecting a cable from the MIDI OUT
jack of the master to the MIDI IN jack of the slave. Additional LXP-15s can be
slaved to the master by connecting a cable from the MIDI THRU port of one slave
unit to the MIDI IN port of the next unit. All of the LXP-15s must be set to the same
MIDI channel.
INPUT OUTPUT
POWER
LXP-15
exicon
HEADROOM
OVL
12
18
24
VIEW
ADJUST PAGE
Reverb
Pitch/EQ
Dly
Setup
Store
Name
Global
MIDI
Level
Mod
Al
Patch 1
Patch 2
Patch
Patch
Sys
INPUT OUTPUT
POWER
LXP-15
exicon
HEADROOM
OVL
12
18
24
VIEW
ADJUST PAGE
Reverb
Pitch/EQ
Dly
Setup
Store
Name
Global
MIDI
Level
Mod
Al
Patch 1
Patch 2
Patch
Patch
Sys
MIDI In
MIDI Out
Master
Slave
When connected in this way, the slave LXP-15(s) will be remotely controlled by
the front panel of the master as follows:
• In general, whenever the master’s ADJUST knob is used to change a
parameter value, a corresponding parameter change will occur on the
slave(s).
• Loading presets or registers from the setup page in either the “Preset” or
“Register” modes will cause the slave(s) to load their preset or register
of the
same number
. (Note: a slave’s register contents will not necessarily be the
same as the master’s.)
• Loading presets or registers in either the “PreScan” or “RegScan” modes will
cause the slave(s) to select the preset and register
of the same number
. The
“Load” button of the slave must be pressed to actually load the preset or
register.
• Changes made on the “Store” page are not transmitted to the slave(s).
Creating Patches using
MIDI SysEx
Patches can also be created using LXP-15 MIDI System Exclusive data. This is
perhaps the most complicated but also the most flexible way of creating patches
to control the LXP-15.
Chapter 7 provides the information necessary for programming LXP-15 MIDI
SysEx data.
