Lexicon LXP-15 User Manual

Lexicon
LXP-15 Owner's Manual
7-6
Parameter Map
Param # Data
(Program parameters)
0 - 26 Microcode Parameters
27 General Purpose Patch 1 Source
28 General Purpose Patch 1 Threshold
29 General Purpose Patch 1 Destination
+30(31) General Purpose Patch 1 Scale
+32(33) General Purpose Patch 1 Offset
34-40 General Purpose Patch 2
41-47 General Purpose Patch 3
48-54 General Purpose Patch 4
55-66 Name (12 characters)
(System parameters)
67 Setup Increment
68 Setup Decrement
69 Display Contrast
70 Display Brightness
71-74 Reserved
75 Register number
76 Preset number
+77(78) Setup number
79 MIDI Channel
80 Global Patch mode
81 Display Update
82 Memory Protect (nonzero=protected)
83-95 Reserved
Param #
Patch 1 Patch 2 Patch 3 Patch 4 Data
27 34 41 48 Patch Source
(0 - 127, see below)
28 35 42 49 Patch Threshold
(0 - 127)
29 36 43 50 Patch Destination
(microcode param # 1-22)
+30(31) +37(38) +44(45) +51(52) Patch Scale Factor
(-64 to +64, 2’s complem.)
+32(33) +39(40) +46(47) +53(54) Patch Offset
Control # Function
0 - 31 Continuous controller 0 - 31
32 - 63 7-bit controllers 32-63
64 Last note played
65 Last note’s velocity
66 Channel aftertouch value
67 Pitch bend value
68 MIDI tempo period
69 LFO value
70 Lowest note held
71 Highest note held
72-76 Foot controllers 1-5
77 Input signal level
MIDI Patch Sources
(General Purpose
and Global)
General Purpose
Patch Parameter Map
