Notes:
When loading preprinted letterhead for onesided printing,
place the header faceup toward the front of the tray.
When loading preprinted letterhead for twosided printing,
place the header facedown toward the rear of the tray.
Onesided printing Twosided printing
LETTERHEAD
LETTERHEAD
Note: Make sure the paper does not exceed the maximum paper
fill indicator located on the left side of the tray.
WarningPotential Damage: Overloading the tray can cause
paper jams and possible printer damage.
6 Insert the tray.
Note: For some paper sizes, the tray will extend past the back of
the printer.
7 From the printer control panel, verify the paper size and paper type
setting for the tray based on the paper you loaded.
Note: Paper jams may occur if the paper size and type settings
selected do not match the paper loaded.
Loading the optional 550sheet special media
tray
The optional 550sheet special media tray (Tray 2), unlike any other
trays, supports narrow paper sizes such as envelopes and A6.
1
2
3
4
1 Primary length guide
2 Length guide lock
3 Secondary length guide
4 Width guide
CAUTION—POTENTIAL INJURY: To reduce the risk of
equipment instability, load each paper drawer or tray
separately. Keep all other trays closed until needed.
Notes:
For instructions on loading paper sizes larger than A6 and
envelopes, see “Loading the standard or an optional 550sheet
tray” on page 2.
For a complete list of supported paper sizes, see the “Supported
paper sizes, types, and weights” section in the User’s Guide.
Loading narrow paper sizes such as envelopes and A6
1
Pull the tray completely out.
Note: Do not remove trays while a job prints or while Busy
appears on the display. Doing so may cause a jam.
2 Squeeze and slide the primary length guide toward you until it
stops.
Notes:
The length has a locking device. To unlock the length guide,
slide to the left the button on top of the length guide. To
lock, slide the button to the right when a length has been
selected.
You can only slide the secondary length guide when the
primary length guide reaches the edge of the width guide.
3

Other manuals for Lexmark C746

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark C746 and is the answer not in the manual?

Lexmark C746 Specifications

General IconGeneral
ColorYes
Print technologyLaser
Resolution color2400 x 600 DPI
Maximum resolution1200 x 1200 DPI
Duplex printing modeAuto/Manual
Time to first page (black, normal)9 s
Print margins (top, bottom, right, left)4.2 mm
Print speed (black, normal quality, A4/US Letter)33 ppm
Printing colorsBlack, Cyan, Magenta, Yellow
Maximum duty cycle85000 pages per month
Recommended duty cycle1500 - 9200 pages per month
Number of print cartridges1
Page description languagesMicrosoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input typePaper tray
Total input capacity650 sheets
Total output capacity300 sheets
Maximum input capacity4300 sheets
Total number of input trays2
Maximum number of input trays6
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight60 - 218 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Wi-FiNo
Security algorithms802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies-
Supported network protocols (IPv4)TCP/IP, AppleTalk
Supported network protocols (IPv6)TCP/IP, TCP, UDP
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)32 dB
Maximum internal memory1536 MB
Sound pressure level (printing)54 dB
Sound pressure level (quiet mode)48 dB
DisplayLCD
CertificationCAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product colorBlack, White
Display diagonal2.4 \
Power consumption (off)6.8 W
Power consumption (standby)48 W
Power consumption (printing)420 W
Server operating systems supportedWindows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude0 - 3048 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Package depth553 mm
Package width588 mm
Package height545 mm
Package weight29700 g
Weight and Dimensions IconWeight and Dimensions
Depth400 mm
Width435 mm
Height455 mm
