Lexmark C746 Quick Reference

4 Squeeze and slide the secondary length guide to the correct
position for the paper size you are loading.
1
2
5 F le x t he she et s back and fort h to loo sen th em . Do not fold or cre as e
the paper. Straighten the edges on a level surface.
6 Load the paper stack with the recommended printable side faceup.
Notes:
• Load envelopes with the stamp side entering the printer
first.
• Make sure the paper does not exceed the maximum paper
fill indicator located on the side of the width guide.
Warning—Potential Damage: Overloading the tray can cause
paper jams and possible printer damage.
7 Insert the tray.
8 From the printer control panel, verify the paper size and paper type
setting for the tray based on the paper you loaded.
Note: Return the secondary length guide back to its original position
when loading long papers such as legal, letter, and A4. Squeeze and
slide the guide until it clicks into place.
Loading the 2,000‑sheet high‑capacity feeder
CAUTION—POTENTIAL INJURY: To reduce the risk of
equipment instability, load each paper drawer or tray
separately. Keep all other drawers or trays closed until
needed.
1 Pull the tray out.
2 Pull up and slide the width guide to the correct position for the
paper size you are loading.
5

Lexmark C746 Specifications

General

Color	Yes
Print technology	Laser
Resolution color	2400 x 600 DPI
Maximum resolution	1200 x 1200 DPI
Duplex printing mode	Auto/Manual
Time to first page (black, normal)	9 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	33 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	85000 pages per month
Recommended duty cycle	1500 - 9200 pages per month
Number of print cartridges	1
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PDF 1.6, PostScript 3, PPDS
Paper input type	Paper tray
Total input capacity	650 sheets
Total output capacity	300 sheets
Maximum input capacity	4300 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Envelopes sizes	7 3/4, 9, 10, B5, C5, DL
Paper tray media types	Card stock, Envelopes, Labels, Plain paper, Transparencies
Paper tray media weight	60 - 218 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Folio (media size), Letter (media size), Oficio (media size), Statement (140 x 216mm), Universal, Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Wi-Fi	No
Security algorithms	802.1x RADIUS, HTTPS, LEAP, MD5, PEAP, SSL/TLS
Mobile printing technologies	-
Supported network protocols (IPv4)	TCP/IP, AppleTalk
Supported network protocols (IPv6)	TCP/IP, TCP, UDP
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Parallel, Serial (RS-232), Wireless LAN
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Noise level (idle)	32 dB
Maximum internal memory	1536 MB
Sound pressure level (printing)	54 dB
Sound pressure level (quiet mode)	48 dB
Display	LCD
Certification	CAN/CSA-C22.2 60950-1, CSA E60825-1, ICES-003 Class A, BSMI Class A, VCCI Class A, US FDA, FCC Class A, UL 60950-1, EN/IEC 60320-1, CE Class A, CB IEC 60950-1, EN 60950-1, EN/IEC 61000-3, EN 55022 Class A, EN 55024, EN/IEC 60825-1, GS (TÜV), AR S (TÜV), SMA C-tick mark Class A, CCC Class A, CISPIR 22 Class A, MIC Mark, EK Mark
Product color	Black, White
Display diagonal	2.4 \
Power consumption (off)	6.8 W
Power consumption (standby)	48 W
Power consumption (printing)	420 W
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012, Windows Server 2012 R2
Operating altitude	0 - 3048 m
Operating temperature (T-T)	16 - 32 °C
Operating relative humidity (H-H)	8 - 80 %
Package depth	553 mm
Package width	588 mm
Package height	545 mm
Package weight	29700 g

Weight and Dimensions

Depth	400 mm
Width	435 mm
Height	455 mm
