Menu item Description
Local Port Timeout
1–100
This allows users to select a timeout value for forms jobs that come
in on any of the local ports (serial, USB, or parallel). This setting
does not apply to forms jobs sent to the network ports. The default
value is 4 seconds.
When Formsmerge is active on a local port, then a job will time out
when triggered by the Local Port Timeout or the Printer Timeout—
whichever is shorter. This terminates the current job as if an “End
of Form” character has been reached.
Copy Formsets
Copy replace duplicates
Copy do not replace
This allows the printer to download forms from a flash drive.
Notes:
• “Copy replace duplicates” allows the user to copy and
replace existing formsets of the same name.
• “Copy do not replace” does not copy formsets with duplicate
names.
• When using this feature, make sure a formsmerge
(case‑sensitive) directory exists in the flash drive.
Barcode menu
The Bar code menu is also available on the Embedded Web server.
Menu item Description
Alt ESC Code
On
Off
This allows the use of an alternate escape character when
processing PCL escape sequences.
Notes:
• This is a Bar Code function.
• On uses an alternate escape code character in addition to
the default escape code character.
• Off uses the default escape code character.
ESC Character
126 (~)
34 (“)
35 (#)
36 ($)
47 (/)
63 (?)
92 (\)
123 ({)
124 (|)
125 (})
When Alt ESC Code is set to On, the value defined in this setting is
used in addition to the default escape character.
Creating and managing forms 17
