Overview
5
1
Overview
The printer is available in two models: Lexmark E120 (base model) with 600 dpi (dots per inch) to 1200 IQ (image quality)
resolution, 8 MB of standard memory, and a USB port; and Lexmark E120n network model) with 600 dpi to 1200 IQ
resolution,16 MB of standard memory, a USB port, and an integrated Ethernet adapter.
Both models have a 150-sheet paper tray (Tray 1), located in the front of the printer, and a multi-sheet priority feeder,
located just above Tray 1. Print media will automatically pick from the priority tray until the supply is emptied, and then pick
from Tray 1 to complete a print job.
Tray 1 has a dual-action slide with an adjustable guide built into the bottom of the tray. The white rectangular piece (slide)
can be pulled out or pushed in to adjust to different print media sizes.
There is a paper support on top of the printer, which can be flipped out to assist with smooth paper stacking in the 50-sheet
output bin.
The printer has three doors: a front door, a top door, and a rear door.
Tray 1 with adjustable
guides
Slide and attached
backstop
Front door release
button
Front door
50-sheet output bin
Operator panel
Top door
Tray 1 cover / Priority
feeder paper path
Priority feeder with
adjustable guides
Paper support

Table of Contents

Other manuals for Lexmark E120

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark E120 and is the answer not in the manual?

Lexmark E120 Specifications

General IconGeneral
Wi-FiNo
Network readyYes
Print technologyLaser
Time to first page (black, normal)8 s
Print speed (black, normal quality, A4/US Letter)19 ppm
Printing colorsBlack
Maximum duty cycle10000 pages per month
Number of print cartridges-
Processor frequency183 MHz
Maximum internal memory16 MB
Sound power level (standby)26 dB
Sound pressure level (printing)49 dB
CertificationFCC B, UL 60950-1, U.S. FDA, IEC 60320-1, CSA 60950-1-03, ICES B, CE B, CB IEC 60950-1, IEC 60825-1, GS (TÜV), SEMKO, UL AR, CS, TÜV Rh, N Mark, ACA C-tick B, CCC B, BSMI B, VCCI B, MIC, EK Mark, PSB
Total input capacity150 sheets
Total output capacity50 sheets
Envelopes sizes7 3/4, 9, 10, B5, C5, DL
Maximum print size216 x 297 mm
Paper tray media typesCard stock, Labels, Plain paper, Transparencies
Paper tray media weight60 - 163 g/m²
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Standard interfacesEthernet, USB 2.0
Optional connectivityEthernet, Wireless LAN
Server operating systems supportedWindows 2000 Advanced Server, Windows 2000 Server, Windows Server 2003, Windows Server 2003 x64
Windows operating systems supportedWindows 2000, Windows 2000 Professional, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 98, Windows ME, Windows Vista Business, Windows Vista Business x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Power consumption (printing)- W
Networking featuresFast Ethernet
Operating altitude0 - 2500 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)388 x 370 x 250 mm
