Lexmark M5150 - Stapler Tray Link Assembly Removal

Stapler tray link assembly removal
Left tray link removal
1
Remove the stapler left cover cover. See “Stapler left cover removal” on page 630.
2 Unhook the spring (A) to release the tray link.
A
3 Remove the three screws (B) securing the controller board. Move the board to access the link underneath it.
4063
Repair information
640
