47
Set up
the op
tional
ma
ilbox
7
Inser
t the
L-pin thr
ough
the hol
es
in the
stabi
lizi
ng foot and back
f
oot.
8
Rotate t
he end o
f the L-pi
n down
into th
e slot in
the
stabili
zing
f
o
ot.
