Lexus LC 500 - Engine Compartment

336
6-3. Do-it-yourself maintenance
 LC500
Fuse box (P.366)
Engine oil level dipstick (P.338)
Engine coolant reservoir (P.341)
Engine oil filler cap (P.339)
Washer fluid tank (P.343)
Air cleaners (P.343)
Electric cooling fan
Condenser (P.342)
Radiator (P.342)
For right-hand drive vehicles:
The fuse box is located on the opposite side of the engine compartment.
Engine compartment
Components
A
B
C
D
E
F
G
H
I
