366
6-3. Do-it-yourself maintenance
1 Turn the engine switch <power
switch> off.
2 Open the fuse box cover.
Engine compartment: type A fuse
box (LC500)
Left-hand drive vehicles:
Push the tab in and lift the lid off.
Right-hand drive vehicles:
Push the tab in and lift the lid off.
Engine compartment: type B fuse
box (LC500h)
Left-hand drive vehicles:
Push the tab in and lift the lid off.
Right-hand drive vehicles:
Push the tab in and lift the lid off.
Engine compartment: type C fuse
box (LC500h)
Push the tab in and lift the lid off.
Trunk
Remove the luggage mat.
Checking and replacing
fuses
If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.
Checking and replacing fuses
