CHASSIS
565
— TRANSFER
Oil capacity
0.9 L (1.0 qt., 0.8 Imp. qt.)
Oil type Hypoid gear oil API GL−5
Recommended oil viscosity Above −18C (0F) SAE 90
Below −18C (0F) SAE 80W or 80W−90
— BRAKES
Pedal clearance
80 mm (3.1 in.) Min. *
1
Pedal free play 2 — 3 mm (0.079 — 0.118 in.)
Brake pad wear limit 1.0 mm (0.04 in.)
Parking brake lining wear limit 1.0 mm (0.04 in.)
Parking brake adjustment 5 — 7 clicks *
2
Fluid type SAE J1703 or FMVSS No.116 DOT 3
*
1
: Minimum pedal clearance when depressed with the pressure of 490 N (50 kgf, 110 lbf) with the engine running
*
2
: Parking brake adjustment when depressed with the pressure of 300 N (31 kgf, 67 lbf)
— STEERING
Wheel free play
Less than 30 mm (1.2 in.)
Power steering fluid type Automatic transmission fluid DEXRON
II or III
