ELECTRICAL COMPONENTS
597
No. FUSE AMPERE CIRCUIT
7 ABS NO. 1 30
Anti−lock brake system, vehicle
stability control system, traction
control system, brake assist
system
8 RR DEF 40 Rear window defogger
9 HEATER 50
Air conditioning system, rear
window defogger
10 DRL 7.5 Daytime running light system
11
H−LP L
LWR
15 Left−hand headlight (low beam)
12
H−LP L
UPR
15 Left−hand headlight (high beam)
13
H−LP R
UPR
15
Right−hand headlight (high
beam)
14
PWR
OUTLET
NO. 2
20 Power outlet
15 TOWING 30 Trailer lights
16 ABS NO. 2 50
Anti−lock brake system, vehicle
stability control system, traction
control system, brake assist
system
No. FUSE AMPERE CIRCUIT
17 RDI FAN 50 Electric cooling fan
18 HAZ 15 Turn signal lights
19 CRT 7.5 Audio system
20 ALT−S 7.5 Charging system
21 ETCS 10
Multiport fuel injection
system/sequential multiport fuel
injection system
22 HORN 10 Horns
23 MAIN 40
Daytime running light system,
left−hand headlight, right−hand
headlight, all components in
“H−LP R LWR”, “H−LP R UPR”,
“H−LP L UPR”, “H−LP L LWR”
and “DRL” fuses
24 AM2 30
Starting system, all components
in “GAUGE NO. 2”, “IGN” and
“INJ” fuses
25
RADIO
NO. 1
15 Audio system, navigation system
To Next Page
