239
7-2. Panoramic view monitor
7
Peripheral monitoring system
Wide front view
Rear view
The area around both corners of
the bumper will not be displayed.
Wide rear view
The area around both corners of
the bumper will not be displayed.
● Black masking is done for distance
detection differences to the front of the
vehicle.
● The area covered by the camera is lim-
ited. Objects which are close to either
corner of the bumper or under the
bumper cannot be seen on the screen.
● The area displayed on the screen may
vary depending on vehicle orientation or
road conditions.
● The camera uses a special lens. The dis-
tance in the image displayed on the
screen will differ from the actual distance.
Area of the image captured by the
camera
