243
7-2. Panoramic view monitor
7
Peripheral monitoring system
When there are three-dimensional objects (such as vehicle bumpers, etc.) nearby
in positions higher than the surface of the road, take extra care when using the fol-
lowing.
Since the panoramic view, Side Clearance View and Cornering View process and
display images based on flat road surfaces, it cannot depict the position of
three-dimension objects (such as vehicle bumpers, etc.) that are in positions higher
than the surface of the road. For example, even though it appears that there is
space between the bumpers of the two vehicles in the illustration below and they
are not likely to collide, in reality, a collision is about to occur.
Distortion of three-dimensional objects on the screen
Panoramic view display (including magnified display), Side Clearance View
and Cornering View display
● When a sensor indicator on the intuitive parking assist display illuminates in red or a
buzzer sounds continuously, be sure to check the area around the vehicle immediately
and do not proceed any further until safety has been ensured, otherwise an unex-
pected accident may occur.
To Next Page
