Description
21300324726_002_C0 - 10/2016 - © Leybold
1.5 Accessories
Required accessories
Set of bolts, nuts and washers for ISO-F flange (12 each) 400153V0012
Bolts M 10 x 50
Bolts M 10 x 35 400153V0010
Bolt quality 12.9 acc. to EN ISO 898-1
with coating; 0,2 % yield strength > 1080 N/mm
2
Centering ring with O-ring DN 200 DN 250
Al/FPM 268 44 268 45
Stainless steel/FPM 887 02 887 08
Set of bolts, nuts and washers for CF flange (8 each) 400153V0016
Bolts M 8 x 40
Bolt quality 10.9 acc. to EN ISO 898-1
with coating; 0,2 % yield strength > 900 N/mm
2
(for DN 200 3 sets required, for DN 250 4 sets)
Copper gasket rings for CF flange
DN 200 (Set of 10 pieces) 839 47
DN 250 (Set of 5 pieces) 839 48
Set of hex. screws with nuts, screws
and washers for CF flange
DN 200 839 07
DN 250 (2 sets required) 839 07
Optional accessories
Mains cable for MAG.DRIVE iM, 2.5 m
EU 411310V03
US 411320V03
Inlet screen
DN 200 ISO-F and DN 200 CF E 200 04 558
DN 250 ISO-F and DN 250 CF E 200 04 557
Seal Kit DN 250 Metal 200 07 901
Seal Kit Metal for other flanges on request
Purge gas and venting valve 24 V DC
0.6 mbar·l/s at 1.5 to 6 bar 121 33
0.6 mbar·l/s at 1 to 1.5 bar 800152V0010
Cable set (2 pieces) for connection to the pump 411300V01
Cooling water valve kit 411300V02
800152V0013
800110V0012
800110V0011
