Operation
23
3.2.8 Parameter list
* specific values for each pump; see table of pumps, Section 3.2.9; r = readable, w = writable
No. Designation min. max. Default Unit r/w Format Description
1 Converter type 100 160 160 - r u16 160 = Turbo.Drive TD20
classic
2 Software version x.yy.zz 0 65535 9059 r u16
3 Actual frequency 0 1000 0 Hz r u16 x.yy: Version, zz: Correction index
4 DC supply voltage 0 1000 0 0.1 V r u16 Rotary frequency of the rotating stator field
5 Actual current 0 100 0 0.1 A r u16 Constantly measured RMS value of the
motor current.
8 Program EEPROM -2147483648 0 w s32 A write command with any number value
2147483647 will initiate carrying over of the data.
11 Actual converter 0 150 0 °C r u16 Constantly measured converter
temperature temperature.
17 Nominal motor current 0 100 70 0.1 A r u16 Maximum motor current
18 Max. frequency 0 1000 * Hz r u16 Upper frequency limit.
19 Minimum setpoint P20 P18 500 Hz r u16 Lowest permissible frequency
frequency for the pump
20 Critical frequency 0 P18 * Hz r u16 When the pump is accelerating this
frequency must be reached within the
maximum passing time (P183).
After the end of acceleration: Switch-off
threshold because of overload.
21 Max. current factor 0 100 73 % r u16 After attaining normal operation,
the maximum motor current is limited
to P17*P21.
23 Pump type 0 99 * r u16 *
24 Setpoint frequency P19 P18 * Hz r u16 Nominal frequency of the rotating stator field.
25 Frequency dependent 70 85 80 % r/w u16 Defines from which frequency onwards
normal operation threshold there is normal operation for the pump.
27 Relay definition 0 P17 20 0.1 A r/w u16 If P29 = 1 or 4: Defines from which motor
normal current current onwards there is the normal
operation.
