Operation
27
No. Designation min. max. Default Unit r/w Format Description
303 Actual operating status 0 65535 0 r u16 Bit 0: Normal operation
Bit 1: Ready for switch on
Bit 2: Speed is increasing
Bit 3: Speed is dropping
Bit 4: Generator operation
Bit 5: Stand-by
Bit 6: reserved
Bit 7: reserved
312 Catalogue number 0 127 800075V0001 r u16 P/N of the converter.
(Index 0...10 usable) One ASCII character per index.
313 Product name 0 127 TD_CLASSIC r u16 Product name of the converter.
(Index 0...10 usable) One ASCII character per index.
315 Serial number converter 0 127 0 r u16 Serial number of the converter.
(Index 0...10 usable) One ASCII character per index.
316 Hardware rev. level 0 65535 0 0.01 r u16 Hardware version index of the converter.
318 Function optional relay 3 0 5 5 R/W u16 0 = Off
1 = On
2 = Warning
3 = Fan (active only for driven pump)
4 = Fan (temperature controlled)
5 = Motor current dependent normal
operation (active for P5 < 27)
918 Active Profibus address 0 126 0 r s16 Address set up at the Profibus adapter.
947 Active failure ID 0 55 0 r s16 Currently present error.
See Section 3.2.10 as to the error codes.
3.2.9 Specific parameter data for the pumps
Type of Pump- Nominal- Critical Maximum Pump housing Pump housing
pump designation and setpoint frequency run-up time warning shutdown
TURBOVAC frequency threshold temperature temperature
P23 P18, P24 P20 P32 P128 P132
0 1100 (C) 500 300 720 70 80
1 1000 (C) 600 350 600 70 80
2 600 (C) 600 350 600 70 80
3 361 (C) 750 450 600 55 65
4 151 (C) 833 550 600 55 65
