3.2.10 Error messages
No. at Error Mode Shut-
0 and 1* 2** down LED Description Condition
0 0 No No error
1 101 No Overload warning P3 < P25*P24 (after normal operation has been
attained) (not during generator operation!).
3 103 No Power supply voltage error Power supply voltage failure during active pump
operation.
4 5 Yes 5 Converter temperature error P11 > limit threshold converter temperature.
6 106 Yes 4 Overload error P3 < P20 after normal operation was attained.
7 6 Yes 3 Run-up time error P3 < P24*P25 after P32 has elapsed with start
signal being present.
8 8 Yes 2 Pump error Pump could not be identified or no pump has
been connected.
10 3 Yes 6 Pumptemperatureerror P127>P132ortemperatureswitch=∞
16 116 Yes 4 Overload duration error P3 < P25*P24 longer of than P32.
17 117 Yes 1 Motor current error No motor current or motor current too low.
19 2 Yes 3 Pass-through time error 60 Hz < P3 < P20 after P183 has elapsed with
the start signal being present
43 143 Yes 8 Internal error
60 4 Yes 7 Hardware monitoring Short-circuit within the motor or connecting cable
(overcurrent, overvoltage, air cooler defective)
62 62 No Pump temperature warning P127 > P128
> 100 > 200 Yes 7 Internal error Error within the converter or external voltage
applied to the inputs
* Error modes 0 and 1 are compatible with TD 1600 and MAG.DRIVE.
** Error mode 2 is the default setting for the TD20
classic
.
The error mode can be set in Parameter 90.
