Operation
29
3.3 Start-up of the TURBOVAC
Press the START key.
The STATUS LED flashes during acceleration. The LED chain indicates the
increasing speed with one LED each. When 80% of the target speed has
been reached, the LED STATUS remains on continuously.
During normal operation the row of LEDs will indicate the amount of power
taken up by the TURBOVAC.
3.4 Operation
During NORMAL operation, the LED STATUS lights and the LED chain
shows, starting at the bottom and moving upwards, the current consumed.
If the target speed of the TURBOVAC cannot be maintained during normal
operation due to overloading (pressure, excessive TURBOVAC or Turbo.Drive
TD20
classic
temperature), the LED ERROR flashes.
The mode is not a failure, but can result in a shut down depending on the
cause of overload, e.g. if the temperature continues to rise.
3.4.1 Status table at default settings
(Parameter 29=0; Normal operation threshold at 80% of the nominal value)
Input data / status Output data Operating mode
Start/ Pump Frequency Error Motor Relay Relay LED LED
stop rotating ≥ 80% of is pre- drive NORMAL ERROR STATUS ERROR
signal setpoint fr. sent OPERATION (green) (red)
Stop no no no off passive passive off off Pump not operating
Stop yes no no off passive passive flashes off Pump is decelerating
Stop yes yes no off passive passive flashes off Just after stop; pump was
in the normal operating
mode before that
Start no no no on passive passive flashes off Just after start
Start yes no no on passive passive flashes off Pump is accelerating
Start yes yes no on active passive on off Pump is in the normal
operating mode
Stop no no yes off passive active off on Error is present; pump is at
standstill or decelerating
Stop yes no yes off passive active flashes on Error is present;
pump is decelerating
Stop yes yes yes off passive active flashes on Error has just occurred
Start no no yes off passive active off on Error is present; pump is at
standstill or decelerating
Start yes no yes off passive active flashes on Error is present;
pump is decelerating
Start yes yes yes off passive active flashes on Error has just occurred
