13. Remove the bolt that locks the Lower Punch with an Allen key.
14. Remove the Lower Punch by hand.
14.1 Note: If you cannot remove by hand, carefully use grippers or pliers.
Replace the Tooling
15. Insert the new Lower Punch into the Lower Drift Pin Assembly.
16. Reinsert the bolt that locks the Lower Punch with an Allen key.
16.1 Note: Make sure that the Lower Punch's “keyed” section is facing forward.
Note: To help ensure that the Die is inserted correctly, LFA
recommends using an Insertion Ring. You can order the Die
Seat Cleaner and Insertion Ring on our website at https://www.
lfatabletpresses.com/die-seat-cleaner-insertion-ring
