LG 84WS70MS - AV(CVBS) connection

44
ENG
ENGLISH
MAKING CONNECTIONS
AUDIO
OUT
VIDEO
OUT
AV(CVBS) connection
Transmits the analog video and audio signals from an external device to the Monitor.
Connect the external device and the Monitor with the 15 pin signal to RCA cable as shown on the following
illustration.
(not included)
(not included)
Back of the product.
