LG 84WS70MS - Page 59

59
ENG
ENGLISH
CONTROLLING THE MULTIPLE PRODUCT
* Real data mapping
Hexadecimal Num.
(Setting Value)
Decimal Num.
(Real Value)
0 0
A 10
F 15
10 16
20 32
64 100
FE 254
FF 255
01. Power(Command: k, a)
To control Power On/Off of the set.
Transmission
[k][a][ ][Set ID][ ][Data][Cr]
Data
00: Power Off
01: Power On
Acknowledgement
[a][ ][Set ID][ ][OK/NG][Data][x]
* The normal acknowledgement signal returns
after the power of the set is turned on completely.
* There might be a time delay between
the transmission and acknowledgement signals.
03. Screen Mute(Command: k, d)
To select screen mute on / off.
Transmission
[k][d][ ][Set ID][ ][Data][Cr]
Data
00: Screen on
01: Screen off
Acknowledgement
[d][ ][Set ID][ ][OK/NG][Data][x]
02. Aspect Ratio(Command: k, c)
To adjust the screen format.
You can also adjust the screen format using the
ARC(Aspect Ratio Control) button on remote control
or in the Screen menu.
Transmission
[k][c][ ][Set ID][ ][Data][Cr]
Data
01: Normal Screen(4:3)
02: Wide Scran(16:9)
04: Zoom(AV, Component, HDMI/ Display Port DTV)
06: Original
09: Just Scan(HDMI1/ HDMI2/ DVI/ Display Port
-DTV)
* Available only with 720p or higher.
10 to 1F: Cinema Zoom 1 to 16(AV, HDMI1/HDMI2/
DVI/Display Port -DTV)
Acknowledgement
[c][ ][Set ID][ ][OK/NG][Data][x]
04. Volume Mute(Command: k, e)
To control On/Off of the Volume Mute.
Transmission
[k][e][ ][Set ID][ ][Data][Cr]
Data
00: Volume Mute On (Volume Off)
01: Volume Mute Off (Volume On)
Acknowledgement
[e][ ][Set ID][ ][OK/NG][Data][x]
05. Volume Control(Command: k, f)
To adjust Volume.
Transmission
[k][f][ ][Set ID][ ][Data][Cr]
Data
Min. 00H to Max. 64H : 0~100
* Refer to 'Real data mapping’.
Acknowledgement
[f][ ][Set ID][ ][OK/NG][Data][x]
