LG CK99 - Appendix; General Specifications

5 Appendix
Appendix
48
Appendix
5
General specifications
General
Power requirements Refer to the main label on the unit.
Power consumption
Refer to the main label on the unit.
Networked standby : 0.5 W
(If all network ports are activated.)
Dimensions (W x H x D) Approx. 470 mm x 213 mm x 423 mm
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Inputs / Outputs
Analog audio in (AUX IN 1/2) 2.0 Vrms (1 kHz, 0 dB), RCA jack (L, R) .
Analog audio out (AUX OUT) 2.0 Vrms (1 kHz, 0 dB), RCA jack (L, R)
Portable in (PORT. IN) 1.0 Vrms (3.5 mm stereo jack) x 1
Microphone (MIC 1/2) Sensitivity 20 mV (1 kHz), 6.3 mm jack x 2
Tuner
FM Tuning Range 87.5 to 108.0 MHz or 87.50 to 108.00 MHz
System
Frequency Response 40 to 20,000 Hz
Signal-to-noise ratio More than 75 dB
Dynamic range More than 80 dB
Bus Power Supply (USB)
5 V 0 500 mA
Amplier (RMS Output power)
Total output 5,000 W RMS
HIGH 1,250 W RMS X 2 (8 Ω at 1 kHz, 30 % THD)
LOW 1,250 W RMS X 2 (8 Ω at 70 kHz, 30 % THD)
y Design and specications are subject to change without notice.
