LG LS091HSV3 Engineering Manual

PRODUCT DATA | 45
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
PERFORMANCE DATA
Cooling Capacity
LSN/LSU240HSV3, LSN/LSU307HV3
Table 20: LSN240HSV3/LSU240HSV3 Cooling Capacities
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 13.32 10.68 0.68 16.66 11.37 0.81 19.99 12.06 0.93 24.16 12.93 1.09 26.66 13.45 1.19 22.25 14.66 0.97 19.30 15.48 0.82
5 13.07 10.53 0.72 16.34 11.21 0.85 19.61 11.89 0.98 23.70 12.74 1.14 26.15 13.26 1.24 21.82 14.46 1.01 18.93 15.26 0.86
7 13.16 10.62 0.72 16.45 11.31 0.86 19.74 12.00 0.99 23.86 12.86 1.15 26.33 13.38 1.25 21.97 14.59 1.02 19.06 15.40 0.87
10 13.29 10.77 0.73 16.62 11.47 0.87 19.95 12.17 1.00 24.10 13.04 1.17 26.60 13.56 1.27 22.20 14.79 1.04 19.26 15.61 0.88
14 13.47 10.96 0.75 16.84 11.67 0.89 20.22 12.38 1.03 24.43 13.27 1.20 26.96 13.81 1.30 22.50 15.06 1.06 19.52 15.89 0.90
23 14.46 11.77 0.74 17.40 12.53 0.90 20.33 13.30 1.05 24.00 14.25 1.24 26.20 14.82 1.36 23.06 16.16 1.08 20.96 17.06 0.90
25 14.69 11.96 0.76 17.56 12.70 0.91 20.43 13.44 1.06 24.02 14.36 1.25 26.18 14.91 1.36 23.31 16.34 1.10 21.40 17.29 0.93
30 15.25 12.42 0.82 17.97 13.10 0.96 20.68 13.79 1.10 24.08 14.64 1.27 26.11 15.15 1.38 23.94 16.77 1.15 22.50 17.85 0.99
35 15.82 12.88 0.87 18.38 13.51 1.00 20.94 14.14 1.13 24.13 14.92 1.29 26.05 15.39 1.39 24.58 17.21 1.19 23.60 18.42 1.06
40 16.39 13.34 0.93 18.79 13.92 1.05 21.19 14.49 1.16 24.19 15.20 1.31 25.99 15.63 1.40 25.21 17.64 1.23 24.70 18.98 1.13
45 16.96 13.81 0.98 19.20 14.32 1.09 21.44 14.84 1.20 24.24 15.48 1.33 25.93 15.87 1.41 25.85 18.08 1.28 25.79 19.55 1.19
50 17.52 14.27 1.04 19.61 14.73 1.13 21.69 15.19 1.23 24.30 15.76 1.35 25.86 16.11 1.42 26.48 18.51 1.32 26.89 20.11 1.26
55 18.09 14.73 1.09 20.02 15.13 1.18 21.95 15.54 1.26 24.36 16.04 1.37 25.80 16.35 1.43 27.12 18.94 1.37 27.99 20.68 1.32
60 18.66 15.19 1.15 20.43 15.54 1.22 22.20 15.89 1.30 24.41 16.33 1.39 25.74 16.59 1.44 27.75 19.38 1.41 29.09 21.24 1.39
65 18.49 15.05 1.21 20.17 15.48 1.28 21.85 15.90 1.35 23.95 16.43 1.43 25.21 16.75 1.49 27.21 19.39 1.47 28.55 21.15 1.46
70 18.32 14.92 1.27 19.91 15.41 1.33 21.50 15.91 1.40 23.48 16.53 1.48 24.67 16.91 1.53 26.68 19.40 1.53 28.02 21.06 1.53
75 18.15 14.78 1.33 19.65 15.35 1.39 21.14 15.92 1.45 23.01 16.64 1.53 24.14 17.07
1.58 26.14 19.41 1.59 27.48 20.98 1.60
80 17.98 14.64 1.38 19.39 15.29 1.44 20.79 15.94 1.50 22.55 16.74 1.58 23.60 17.23 1.62 25.61 19.42 1.65 26.94 20.89 1.68
85 17.81 14.51 1.44 19.12 15.23 1.50 20.44 15.95 1.56 22.08 16.85 1.63 23.07 17.39 1.67 25.07 19.44 1.72 26.40 20.80 1.75
90 17.64 14.37 1.50 18.86 15.16 1.55 20.09 15.96 1.61 21.62 16.95 1.67 22.53 17.55 1.71 24.53 19.45 1.78 25.87 20.71 1.82
95 17.47 14.23 1.56 18.60 15.10 1.61 19.74 15.97 1.66 21.15 17.06 1.72 22.00 17.71 1.76 24.00 19.46 1.84 25.33 20.62 1.89
100 17.01 13.86 1.58 18.17 14.77 1.63 19.34 15.68 1.69 20.79 16.81 1.75 21.66 17.50 1.79 23.58 19.15 1.86 24.87 20.25 1.92
105 16.56 13.48 1.61 17.75 14.43 1.66 18.94 15.38 1.71 20.42 16.57 1.77 21.31 17.29 1.81 23.17 18.84 1.89 24.41 19.87 1.94
110 16.10 13.11 1.63 17.32 14.10 1.68 18.54 15.09 1.74 20.06 16.33 1.80 20.97 17.07 1.84 22.76 18.53 1.92 23.95 19.50 1.97
115 15.53 12.64 1.65 16.70 13.60 1.70 17.88 14.57 1.75 19.35 15.77 1.82 20.24 16.50 1.86 21.98 17.90 1.94 23.14 18.84 2.00
118 15.18 12.36 1.66 16.34 13.31 1.71 17.49 14.26 1.77 18.93 15.44 1.83 19.80 16.15 1.87 21.52 17.53 1.95 22.66 18.45 2.01
122 14.72 12.61 1.68 15.84 13.57 1.73 16.97 14.54 1.78 18.37 15.75 1.85 19.21 16.48 1.89 20.87 17.88 1.97 21.98 18.82 2.03
Table 21: LSN307HV3/LSU307HV3 Cooling Capacities
DB: Dry Bulb Temperature (°F) WB: Wet Bulb Temperature (°F) TC: Total Capacity (kBtu/h)
SHC: Sensible Capacity (kBtu/h) PI: Power Input (kW) (includes compressor, indoor fan motor and
outdoor fan motor)
1. All capacities are net, evaporator fan motor heat is deducted.
2. Cooling range with the Low Ambient Baffle Kit (sold separately) is 0°F to +122°F.
3. Grey shading indicates reference data. When operating the unit at this temperature, these values
can be different by discontinuous operation.
4. Direct interpolation is permissible. Do not extrapolate.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 18.16 14.56 1.17 22.71 15.51 1.38 27.26 16.45 1.59 32.94 17.63 1.86 36.35 18.34 2.02 30.34 20.00 1.65 26.32 21.10 1.40
5 17.82 14.36 1.22 22.28 15.29 1.44 26.74 16.22 1.67 32.31 17.38 1.95 35.66 18.08 2.11 29.75 19.71 1.72 25.82 20.80 1.46
7 17.94 14.49 1.23 22.43 15.43 1.46 26.92 16.37 1.68 32.54 17.54 1.97 35.90 18.24 2.14 29.96 19.89 1.74 26.00 21.00 1.48
10 18.12 14.69 1.25 22.66 15.64 1.48 27.20 16.59 1.71 32.87 17.78 2.00 36.27 18.49 2.17 30.27 20.17 1.77 26.26 21.28 1.50
14 18.37 14.95 1.28 22.97 15.92 1.51 27.57 16.89 1.75 33.31 18.10 2.04 36.76 18.83 2.22 30.68 20.53 1.81 26.62 21.67 1.53
23 19.72 16.05 1.26 23.72 17.09 1.53 27.72 18.13 1.79 32.73 19.43 2.12 35.73 20.21 2.32 31.44 22.04 1.85 28.58 23.27 1.53
25 20.03 16.31 1.30 23.94 17.31 1.56 27.86 18.32 1.81 32.76 19.58 2.13 35.69 20.34 2.33 31.79 22.28 1.88 29.18 23.58 1.58
30 20.80 16.94 1.39 24.50 17.87 1.63 28.21 18.80 1.87 32.83 19.96 2.17 35.61 20.66 2.34 32.65 22.87 1.95 30.68 24.34 1.69
35 21.58 17.57 1.49 25.06 18.42 1.71 28.55 19.28 1.93 32.91 20.35 2.20 35.52 20.99 2.36 33.52 23.46 2.03 32.18 25.11 1.80
40 22.35 18.20 1.58 25.62 18.98 1.78 28.89 19.76 1.98 32.98 20.73 2.23 35.44 21.31 2.38 34.38 24.06 2.10 33.68 25.88 1.92
45 23.12 18.83 1.68 26.18 19.53 1.86 29.24 20.23 2.04 33.06 21.11 2.26 35.35 21.64 2.40 35.25 24.65 2.18 35.17 26.65 2.03
50 23.90 19.46 1.77 26.74 20.08 1.93 29.58 20.71 2.09 33.14 21.50 2.30 35.27 21.97 2.42 36.11 25.24 2.25 36.67 27.42 2.14
55 24.67 20.09 1.87 27.30 20.64 2.01 29.93 21.19 2.15 33.21 21.88 2.33 35.18 22.29 2.44 36.98 25.83 2.33 38.17 28.19 2.26
60 25.45 20.72 1.96 27.86 21.19 2.08 30.27 21.67 2.21 33.29 22.26 2.36 35.10 22.62 2.45 37.84 26.43 2.40 39.67 28.96 2.37
65 25.21 20.53 2.06 27.50 21.11 2.18 29.79 21.68 2.30 32.65 22.40 2.44 34.37 22.84 2.53 37.11 26.44 2.51 38.94 28.84 2.49
70 24.98 20.34 2.16 27.15 21.02 2.27 29.31 21.70 2.39 32.02 22.55 2.53 33.64 23.06 2.61 36.38 26.46 2.61 38.20 28.72 2.61
75 24.75 20.15 2.26 26.79 20.93 2.37 28.83 21.71 2.47 31.38 22.69 2.61 32.91 23.28
2.69 35.65 26.47 2.72 37.47 28.60 2.73
80 24.52 19.97 2.36 26.44 20.85 2.46 28.35 21.73 2.56 30.75 22.83 2.69 32.19 23.49 2.77 34.92 26.49 2.82 36.74 28.48 2.86
85 24.29 19.78 2.46 26.08 20.76 2.56 27.87 21.75 2.65 30.11 22.98 2.77 31.46 23.71 2.84 34.19 26.50 2.92 36.01 28.36 2.98
90 24.05 19.59 2.56 25.72 20.68 2.65 27.39 21.76 2.74 29.48 23.12 2.85 30.73 23.93 2.92 33.46 26.52 3.03 35.27 28.24 3.10
95 23.82 19.41 2.66 25.37 20.59 2.74 26.91 21.78 2.83 28.84 23.26 2.94 30.00 24.15 3.00 32.72 26.53 3.13 34.54 28.12 3.22
100 23.20 18.90 2.70 24.78 20.14 2.79 26.37 21.38 2.87 28.34 22.93 2.98 29.53 23.86 3.05 32.16 26.11 3.18 33.91 27.61 3.27
105 22.58 18.38 2.74 24.20 19.68 2.83 25.82 20.98 2.91 27.85 22.60 3.02 29.06 23.57 3.09 31.60 25.69 3.22 33.29 27.10 3.31
110 21.95 17.87 2.78 23.61 19.23 2.87 25.28 20.58 2.96 27.35 22.27 3.07 28.60 23.28 3.14 31.03 25.27 3.27 32.66 26.59 3.36
115 21.17 17.24 2.81 22.78 18.55 2.90 24.38 19.87 2.99 26.39 21.51 3.10 27.60 22.50 3.17 29.98 24.42 3.31 31.56 25.69 3.40
118 20.70 16.85 2.83 22.28 18.15 2.92 23.85 19.44 3.01 25.82 21.06 3.12 27.00 22.03 3.19 29.34 23.90 3.33 30.90 25.16 3.43
122 20.08 17.19 2.86 21.61 18.51 2.95 23.13 19.83 3.04 25.04 21.48 3.15 26.19 22.47 3.22 28.46 24.38 3.36 29.97 25.66 3.46
