LG LS091HSV3 Engineering Manual

46 | PRODUCT DATA
High Efciency, Standard and Extended Pipe Wall Mount Engineering Manual
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 12.81 9.92 0.75 14.04 10.87 0.77 14.83 11.48 0.79 15.83 12.26 0.82 16.74 12.96 0.84 17.41 13.48 0.88 18.86 14.60 0.90
17 12.92 10.00 0.75 14.39 11.14 0.77 15.21 11.77 0.79 16.24 12.57 0.82 17.37 13.45 0.84 18.08 14.00 0.88 19.34 14.97 0.90
23 14.31 11.08 0.74 15.38 11.91 0.77 16.45 12.74 0.79 17.52 13.57 0.81 18.85 14.59 0.84 19.66 15.22 0.87 20.73 16.05 0.90
59 17.35 13.43 0.86 18.65 14.44 0.88 19.95 15.45 0.91 21.25 16.45 0.94 21.84 16.91 0.97 23.85 18.46 1.01 25.14 19.47 1.04
70 19.80 15.33 1.26 21.12 16.35 1.30 22.44 17.38 1.34 23.32 18.06 1.38 23.98 18.57 1.43 25.74 19.93 1.48 27.50 21.29 1.53
75 19.55 15.13 1.30 20.87 16.16 1.34 22.20 17.19 1.38 23.10 17.89 1.42 23.76 18.40 1.47 25.41 19.67 1.53 27.28 21.12 1.57
80 19.03 14.74 1.36 20.36 15.76 1.40 21.68 16.79 1.44 22.66 17.55 1.49 23.54 18.23 1.53 25.08 19.42 1.59 26.84 20.78 1.64
85 18.53 14.35 1.45 19.85 15.37 1.49 21.16 16.39 1.54 22.22 17.20 1.59 23.10 17.89 1.64 24.75 19.16 1.70 26.44 20.47 1.75
90 18.02 13.95 1.51 19.34 14.97 1.56 20.65 15.99 1.61 21.78 16.86 1.66 22.66 17.55 1.71 24.42 18.91 1.78 25.91 20.06 1.83
95 17.47 13.53 1.56 18.78 14.54 1.61 20.09 15.56 1.66 21.40 16.57 1.71 22.00 17.03 1.76 24.02 18.60 1.83 25.33 19.61 1.89
100 17.02 13.18 1.58 18.33 14.19 1.63 19.63 15.20 1.68 20.94 16.22 1.74 21.71 16.81 1.79 23.56 18.24 1.86 24.87 19.26 1.92
105 16.56 12.82 1.61 17.87 13.84 1.66 19.18 14.85 1.71 20.48 15.86 1.76 21.43 16.59 1.82 23.10 17.89 1.89 24.41 18.90 1.95
110 16.10 12.47 1.63 17.41 13.48 1.68 18.72 14.49 1.73 20.03 15.51 1.78 20.97 16.24 1.84 22.64 17.53 1.91 23.95 18.55 1.97
115 15.64 12.11 1.64 16.95 13.13 1.69 18.26 14.14 1.75 19.57 15.15 1.80 20.52 15.88 1.86 22.19 17.18 1.93 23.50 18.19 1.99
118 15.18 11.75 1.66 16.50 12.78 1.71 17.60 13.63 1.76 18.92 14.65 1.82 19.80 15.33 1.87 21.45 16.61 1.95 22.66 17.55 2.01
Table 23: LSN240HLV/LSU240HLV Cooling Capacities
Table 22: LSN360HV3/LSU360HV3 Cooling Capacities
DB: Dry Bulb Temperature (°F) WB: Wet Bulb Temperature (°F) TC: Total Capacity (kBtu/h)
SHC: Sensible Capacity (kBtu/h) PI: Power Input (kW) (includes compressor, indoor fan motor and
outdoor fan motor)
1. All capacities are net, evaporator fan motor heat is deducted.
2. Cooling range with the Low Ambient Baffle Kit (sold separately) is 0°F to +122°F.
3. Grey shading indicates reference data. When operating the unit at this temperature, these values
can be different by discontinuous operation.
4. Direct interpolation is permissible. Do not extrapolate.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
0 19.98 16.02 1.57 24.98 17.06 1.86 29.99 18.09 2.14 36.24 19.39 2.50 39.99 20.17 2.72 33.37 22.00 2.22 28.95 23.21 1.88
5 19.60 15.79 1.64 24.50 16.81 1.94 29.41 17.84 2.24 35.54 19.12 2.62 39.23 19.88 2.85 32.73 21.68 2.32 28.40 22.88 1.97
7 19.73 15.94 1.66 24.67 16.97 1.96 29.61 18.00 2.27 35.79 19.29 2.65 39.50 20.07 2.88 32.96 21.88 2.35 28.60 23.10 1.99
10 19.94 16.15 1.69 24.93 17.20 2.00 29.92 18.25 2.30 36.16 19.56 2.69 39.90 20.34 2.92 33.29 22.18 2.38 28.89 23.41 2.02
14 20.21 16.45 1.72 25.26 17.51 2.04 30.32 18.58 2.35 36.65 19.91 2.75 40.44 20.71 2.98 33.74 22.58 2.43 29.28 23.83 2.07
23 21.69 17.66 1.70 26.09 18.80 2.05 30.50 19.94 2.41 36.00 21.37 2.85 39.30 22.23 3.12 34.58 24.25 2.49 31.44 25.59 2.07
25 22.03 17.94 1.75 26.34 19.04 2.10 30.65 20.15 2.44 36.03 21.54 2.87 39.26 22.37 3.13 34.96 24.51 2.53 32.10 25.93 2.13
30 22.88 18.63 1.88 26.95 19.65 2.20 31.03 20.68 2.52 36.12 21.96 2.92 39.17 22.73 3.16 35.92 25.16 2.63 33.75 26.78 2.28
35 23.73 19.32 2.00 27.57 20.26 2.30 31.40 21.20 2.59 36.20 22.38 2.96 39.08 23.09 3.18 36.87 25.81 2.73 35.40 27.63 2.43
40 24.58 20.02 2.13 28.18 20.87 2.40 31.78 21.73 2.67 36.28 22.80 3.00 38.98 23.45 3.21 37.82 26.46 2.83 37.04 28.47 2.58
45 25.44 20.71 2.26 28.80 21.48 2.50 32.16 22.26 2.74 36.37 23.22 3.05 38.89 23.80 3.23 38.77 27.11 2.93 38.69 29.32 2.73
50 26.29 21.40 2.39 29.41 22.09 2.60 32.54 22.78 2.82 36.45 23.65 3.09 38.80 24.16 3.26 39.72 27.77 3.03 40.34 30.17 2.89
55 27.14 22.09 2.51 30.03 22.70 2.70 32.92 23.31 2.90 36.53 24.07 3.14 38.70 24.52 3.28 40.67 28.42 3.14 41.99 31.01 3.04
60 27.99 22.79 2.64 30.65 23.31 2.81 33.30 23.83 2.97 36.62 24.49 3.18 38.61 24.88 3.31 41.63 29.07 3.24 43.64 31.86 3.19
65 27.74 22.58 2.77 30.25 23.22 2.93 32.77 23.85 3.09 35.92 24.65 3.29 37.81 25.12 3.41 40.82 29.09 3.38 42.83 31.73 3.35
70 27.48 22.38 2.91 29.86 23.12 3.06 32.24 23.87 3.21 35.22 24.80 3.40 37.01 25.36 3.52 40.02 29.10 3.52 42.02 31.60 3.52
75 27.23 22.17 3.04 29.47 23.03 3.19 31.72 23.89 3.33 34.52 24.96 3.51 36.21 25.60
3.62 39.21 29.12 3.66 41.22 31.46 3.68
80 26.97 21.96 3.18 29.08 22.93 3.31 31.19 23.90 3.45 33.82 25.12 3.62 35.40 25.84 3.73 38.41 29.14 3.80 40.41 31.33 3.85
85 26.72 21.76 3.31 28.69 22.84 3.44 30.66 23.92 3.57 33.12 25.27 3.73 34.60 26.08 3.83 37.61 29.15 3.94 39.61 31.20 4.01
90 26.46 21.55 3.45 28.30 22.75 3.57 30.13 23.94 3.69 32.42 25.43 3.84 33.80 26.32 3.94 36.80 29.17 4.08 38.80 31.07 4.17
95 26.21 21.35 3.58 27.90 22.65 3.70 29.60 23.96 3.81 31.73 25.59 3.95 33.00 26.57 4.04 36.00 29.19 4.22 38.00 30.93 4.34
100 25.52 20.78 3.63 27.26 22.15 3.75 29.00 23.52 3.87 31.18 25.22 4.01 32.49 26.25 4.10 35.38 28.72 4.28 37.31 30.37 4.40
105 24.84 20.22 3.69 26.62 21.65 3.81 28.40 23.08 3.93 30.63 24.86 4.07 31.97 25.93 4.16 34.76 28.26 4.34 36.62 29.81 4.46
110 24.15 19.66 3.74 25.98 21.15 3.86 27.80 22.64 3.98 30.09 24.49 4.13 31.46 25.61 4.22 34.14 27.79 4.40 35.93 29.25 4.52
115 23.29 18.96 3.78 25.06 20.41 3.91 26.82 21.85 4.03 29.03 23.66 4.18 30.36 24.75 4.27 32.97 26.86 4.45 34.72 28.26 4.58
118 22.77 18.54 3.81 24.50 19.96 3.93 26.24 21.38 4.05 28.40 23.16 4.20 29.70 24.23 4.29 32.27 26.29 4.49 33.99 27.67 4.61
122 22.09 18.91 3.85 23.77 20.36 3.97 25.45 21.81 4.09 27.55 23.63 4.24 28.81 24.71 4.34 31.31 26.82 4.53 32.97 28.23 4.66
PERFORMANCE DATA
Cooling Capacity
LSN/LSU360HV3, LSN/LSU240HLV
DB: Dry Bulb Temperature (°F) WB: Wet Bulb Temperature (°F) TC: Total Capacity (kBtu/h)
SHC: Sensible Capacity (kBtu/h) PI: Power Input (kW) (includes compressor,indoor fan motor and
outdoor fan motor)
1. All capacities are net, evaporator fan motor heat is deducted.
2. Direct interpolation is permissable. Do not extrapolate.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
