PRODUCT DATA | 47
Product Data
Due to our policy of continuous product innovation, some specications may change without notication.
©
LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Cooling Capacity
PERFORMANCE DATA
LSN/LSU300HLV, LSN/LSU360HLV
DB: Dry Bulb Temperature (°F) WB: Wet Bulb Temperature (°F) TC: Total Capacity (kBtu/h)
SHC: Sensible Capacity (kBtu/h) PI: Power Input (kW) (includes compressor,indoor fan motor and
outdoor fan motor)
1. All capacities are net, evaporator fan motor heat is deducted.
2. Direct interpolation is permissable. Do not extrapolate.
Nominal capacity as rated: 0 ft. above sea level with 25 ft. of refrigerant piping.
0 ft. level difference between outdoor and indoor units.
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and
67ºF wet bulb (WB), and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Table 24: LSN300HLV/LSU300HLV Cooling Capacities
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 17.47 13.52 1.27 19.14 14.82 1.31 20.22 15.65 1.35 21.59 16.72 1.39 22.82 17.67 1.44 23.74 18.38 1.50 25.72 19.91 1.54
17 17.62 13.64 1.27 19.63 15.20 1.31 20.73 16.05 1.35 22.14 17.15 1.40 23.69 18.34 1.44 24.66 19.10 1.50 26.37 20.42 1.54
23 19.51 15.10 1.27 20.97 16.24 1.31 22.43 17.37 1.35 23.89 18.50 1.39 25.70 19.90 1.43 26.81 20.76 1.49 28.27 21.89 1.53
59 23.66 18.32 1.46 25.43 19.69 1.51 27.20 21.06 1.55 28.97 22.43 1.60 29.79 23.06 1.65 32.52 25.18 1.72 34.29 26.55 1.77
70 27.00 20.91 2.15 28.80 22.30 2.22 30.60 23.69 2.29 31.80 24.62 2.36 32.70 25.32 2.43 35.10 27.18 2.53 37.50 29.04 2.60
75 26.65 20.64 2.21 28.46 22.04 2.28 30.27 23.44 2.35 31.50 24.39 2.43 32.40 25.09 2.50 34.65 26.83 2.60 37.20 28.80 2.68
80 25.96 20.10 2.31 27.76 21.49 2.38 29.56 22.89 2.46 30.90 23.93 2.53 32.10 24.86 2.61 34.20 26.48 2.71 36.60 28.34 2.80
85 25.27 19.56 2.47 27.06 20.95 2.55 28.86 22.35 2.63 30.30 23.46 2.71 31.50 24.39 2.79 33.75 26.13 2.90 36.05 27.91 2.99
90 24.57 19.03 2.58 26.37 20.42 2.66 28.16 21.80 2.74 29.70 23.00 2.82 30.90 23.93 2.91 33.30 25.78 3.03 35.33 27.36 3.12
95 23.83 18.45 2.66 25.61 19.83 2.74 27.40 21.21 2.82 29.18 22.60 2.91 30.00 23.23 3.00 32.75 25.36 3.12 34.53 26.74 3.21
100 23.20 17.97 2.70 24.99 19.35 2.78 26.77 20.73 2.87 28.56 22.11 2.96 29.61 22.93 3.05 32.13 24.88 3.17 33.91 26.26 3.27
105 22.58 17.48 2.74 24.37 18.87 2.83 26.15 20.25 2.92 27.93 21.63 3.01 29.22 22.63 3.10 31.50 24.39 3.22 33.29 25.77 3.32
110 21.96 17.00 2.78 23.74 18.38 2.86 25.53 19.76 2.95 27.31 21.15 3.04 28.60 22.14 3.14 30.88 23.91 3.26 32.66 25.29 3.36
115 21.33 16.52 2.80 23.12 17.90 2.89 24.90 19.28 2.98 26.69 20.66 3.07 27.98 21.66 3.17 30.26 23.43 3.29 32.04 24.81 3.39
118 20.70 16.03 2.83 22.50 17.42 2.92 24.00 18.58 3.01 25.80 19.98 3.10 27.00 20.91 3.20 29.25 22.65 3.32 30.90 23.93 3.42
Table 25: LSN360HLV/LSU360HLV Cooling Capacities
Outdoor
Air
Temp.
(°F DB)
Indoor Air Temperature (°F DB/ °F WB)
64 / 53 68 / 57 72 / 61 77 / 64 80 / 67 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
14 19.21 14.88 1.71 21.05 16.30 1.77 22.24 17.22 1.82 23.75 18.39 1.88 25.10 19.44 1.94 26.12 20.22 2.01 28.29 21.90 2.07
17 19.38 15.00 1.72 21.59 16.72 1.77 22.81 17.66 1.82 24.36 18.86 1.88 26.06 20.17 1.94 27.13 21.00 2.02 29.01 22.46 2.08
23 21.46 16.62 1.71 23.07 17.86 1.76 24.67 19.10 1.81 26.28 20.35 1.87 28.27 21.89 1.93 29.49 22.84 2.01 31.10 24.08 2.07
59 26.02 20.15 1.97 27.97 21.66 2.03 29.92 23.17 2.09 31.87 24.68 2.16 32.76 25.37 2.22 35.77 27.70 2.31 37.72 29.20 2.38
70 29.70 23.00 2.90 31.68 24.53 2.99 33.66 26.06 3.08 34.98 27.09 3.18 35.97 27.85 3.27 38.61 29.90 3.41 41.25 31.94 3.51
75 29.32 22.70 2.98 31.31 24.24 3.07 33.29 25.78 3.17 34.65 26.83 3.27 35.64 27.60 3.37 38.12 29.51 3.50 40.92 31.68 3.61
80 28.55 22.11 3.11 30.53 23.64 3.21 32.52 25.18 3.31 33.99 26.32 3.41 35.31 27.34 3.51 37.62 29.13 3.66 40.26 31.17 3.77
85 27.79 21.52 3.33 29.77 23.05 3.43 31.75 24.58 3.54 33.33 25.81 3.64 34.65 26.83 3.76 37.13 28.75 3.91 39.66 30.71 4.02
90 27.03 20.93 3.47 29.00 22.46 3.58 30.98 23.99 3.69 32.67 25.30 3.80 33.99 26.32 3.92 36.63 28.36 4.08 38.87 30.09 4.20
95 26.21 20.30 3.58 28.17 21.82 3.69 30.14 23.33 3.80 32.10 24.85 3.92 33.00 25.55 4.04 36.03 27.89 4.20 37.99 29.41 4.33
100 25.53 19.76 3.64 27.49 21.28 3.75 29.45 22.80 3.86 31.41 24.32 3.98 32.57 25.22 4.11 35.34 27.36 4.27 37.30 28.88 4.40
105 24.84 19.23 3.70 26.80 20.75 3.81 28.76 22.27 3.93 30.73 23.79 4.05 32.14 24.89 4.18 34.65 26.83 4.34 36.62 28.35 4.47
110 24.15 18.70 3.74 26.12 20.22 3.85 28.08 21.74 3.97 30.04 23.26 4.10 31.46 24.36 4.22 33.97 26.30 4.39 35.93 27.82 4.52
115 23.47 18.17 3.77 25.43 19.69 3.89 27.39 21.21 4.01 29.36 22.73 4.13 30.77 23.83 4.26 33.28 25.77 4.43 35.24 27.29 4.57
118 22.77 17.63 3.81 24.75 19.16 3.93 26.40 20.44 4.05 28.38 21.97 4.17 29.70 23.00 4.30 32.18 24.91 4.47 33.99 26.32 4.61
