Chapter 5 32
PIN# Description
1
GND
2
GND
3
SP_R+
4
SP_R+
5
SP_R-
6
SP_R-
7
SP_L+
8
SP_L+
9
SP_L-
10
SP_L-
11
GPIO0
12
GPIO1
13
LEDW EN
14
LEDB EN
15
LED0
16
LED1
17
GND
18
GND
19
LED2
20
LED3
21
LED4
22
LED5
23
P3P3V_STBY_PWR
24
P3P3V_STBY_PWR
25
P3P3V_STBY_PWR
26
LEDS EN
27
IR 1
28
KEY AUTO
CN2 : Keypad Control
