LG RD-JS31 - Thermal Connector (J2); Video & S-Video IN Connectors (J3, J15); Video Connector (CON2); S-Video Connector (CON3)

33 Chapter 5
CON2 : Video
PIN# Description
1
CVBS
2
AGND
CON3 : S-Video
PIN# Description
1
AGND
2
AGND
3
SVDOY
4
SVDOC
PIN# Description
1
COMPVID
2
AGND
3
SVID_LUM
4
AGND
5
SVID_CHR
6
GND
7
+ 3.3 V
8
+ 3.3 V
J3 , J15 : Video & S-Videop IN
PIN# Description
1
+ 3.3 V
2
SCL
3
SDA
4
GND
J2 :Thermal
