LG RD-JS31 - D-SUB Connector (CON1); Phone jack Stereo-R Connector (J7); Color Wheel Connector (J8)

Chapter 5 34
J7 : Phone jack Stereo-R
PIN# Description
1
GND
2
AINC_L
3
NC
4
AINC_R
5
NC
CON1 : D_SUB
PIN# Description
1
V- Red
2
V-Green
3
V-Blue
4
NC
5
AGND
6
AGND
7
AGND
8
AGND
9
+5V
10
DSUB_Detect
11
AGND
12
VSDA
13
H-Sync
14
V-Sync
15
VSCL
PIN# Description
1
CW CTR
2
CW Y3
3
CW Y2
4
CW Y1
J8 : Color Wheel
