35 Chapter 5
JP1 : USB
PIN# Description
1
+5V_STBY
2
GND
3
GND
4
+5V
5
+5V
6
GND
7
+13.5V
8
GND
9
+12.5V
10
GND
J9 : Power Supply
PIN# Description
1
NC
2
USB DATN
3
USB DATP
4
GND
5
GND
6
GND
:
PowerIn
PIN# Description
1
+3.3V
2
+3.3V
3
+3.3V
4
GND
JP3 : CW Index
PIN# Description
1
STBY_PWR
2
GND
JP3 : CW Index
