Chapter 5 36
PIN# Description
1
GND
2
GND
3
TMSI
4
TDO1_OUT
5
SYSRSTZ
6
TRSTZ
7
TDI
8
TMS2
9
TCK
10
RTCK
11
TDO2
12
ICE_RSTZ
13
TRACEPKT15
14
TRACEPKT14
15
TRACEPKT13
16
TRACEPKT12
17
TRACEPKT11
18
TRACEPKT10
19
TRACEPKT9
20
TRACEPKT8
21
TRACEPKT7
22
TRACEPKT6
23
TRACEPKT5
24
TRACEPKT4
25
TRACEPKT3
26
TRACEPKT2
27
TRACEPKT1
28
TRACEPKT0
29
TRACECLK
30
TRACESYNC
31
PIPESTAT0
32
PIPESTAT1
33
PIPESTAT2
34
+3.3V
35
+3.3V
36
+3.3V
JP4 : FirmWare Debug
