F i g . 1 d --- E v a p o r a t i n g u n i t H P S E 1 2 --- 1 4 (version without freecooling)
28,5 903 28,5
375
226.5 150 150 150 226.5
13,593313,5
903
903
FRONT VIEW
TOP VIEW
BOTTOM VIEW
375
903
960
LEFT SIDE VIEW
RIGHT SIDE VIEW
Condensate drain
80994
14.5
Electrical
connection
N. 8 slots 9x12---
unit fixing
Refrigerant connection
