Lifting speed/ temperature:
o
F
o
C
in/sec
mm/sec
+104
o
F
- 41
o
F
+40 ˚C
- +5 ˚C:
1.57”
40 mm
+41
o
F
- 23
o
F
+5 ˚C
- -5 ˚C:
0.79”
20 mm
+23
o
F
- -4
o
F
-5 ˚C
- -20 ˚C:
0.39”
10 mm
Max. 440 lbs/200 kg
-4
o
F
- -13
o
F
-20 ˚C
- -25 ˚C:
0.39”
10 mm
Approval: Directive 2006/42/EC on machinery
Duty cycle: 2 min. / 5 min.
Battery capacity: 30 cycles at 25˚C
Flat battery: 10 min. charge = one trip
Fully charged = 5 hours
All radio components comply with the following regulations and standards:
EU 2014/53/EU, Radio Equipment Directive (RED)
FCC (USA) CFR 47 Part 15
EN 62479:2010 Human exposure
EN 300 440, v2.1.1 Electromagnetic compatibility + Radio spectrum Matters Draft
EN 301489-1, v2.2.0 Electromagnetic compatibility + Radio spectrum Matters Draft
EN301489-17, v3.2.0 Electromagnetic compatibility + Radio spectrum Matters
AS/NZS 4268 Radio Equipment and Systems –Short Range devices
AS/NZS 2772.2 Radio Frequency Fields (mean power < 1 mW)
Internal receiver in EasyLift (MODULE1)
2,4 GHz Short Range devices. FCC ID: 2AK8H-MODULE1
Receiver Class 3
Dimensions (L x W x H): 72 x 33 x 10mm / 2,83 x 1,30 x 0,40 in.
Weight: 10 g (0,035 lbs.)
Frequencies: 2,410 GHz 2,435 GHz and 2,460 GHz
Duty cycle: < 1% (only TX for pairing Remotes)
Power: < 0,6mW Controlled environment
Supply: 5,6 Volt 30mA
Water and dust: IP XX (shall be mounted inside Liftup products)
Working temperature: +5ºC to +40ºC/ 41ºF to 104ºF
Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF
Expected service life: > 5 years
Handheld wireless remote control (REMOTE1)
2,4 GHz Short Range devices. FCC ID: 2AK8H-REMOTE1
Receiver Class 3
Dimensions (L x W x H): 96 x 47 x 24mm / 3,79 x 1,85 x 0,95 in.
Weight: 48 g (0,11 lbs.)
Frequencies: 2,410 GHz 2,435 GHz and 2,460 GHz
Duty cycle: < 1%
Power: <0,6mW Controlled environment, Hold to run
Battery: 3 Volt CR2032
Water and dust: IP 42
Working temperature: +5ºC to +40ºC / 41ºF to 104ºF
Storage temperature: -25ºC to +70ºC / 13ºF to 158ºF
Expected service life: > 5 years
