 UCX series – User's Manual 128


DIFFERENCE:  #new
BAUD Rate Setting
Command and Response #rs-232 #rs232
ç <serial_port>.Baudrate=<baudrate>
æ <serial_port>.Baudrate=<baudrate>
Parameters

Parameter
description
Parameter values
<serial_port> Serial port
number
P1-P2*
<baudrate> Baud rate value 9600
19200
38400
57600
115200
*The UCX-2x1-HC30 model has one serial port (P1).
Example
ç 
æ pw /V1
Stop Bits Setting
Command and Response #rs-232 #rs232
ç <serial_port>.StopBits=<stopbits>
æ <serial_port>.StopBits=<stopbits>
Parameters

Parameter
description
Parameter values
<serial_port> Serial port
number
P1-P2*
<stopbits> Stop bit value 1
2
*The UCX-2x1-HC30 model has one serial port (P1).
Example
ç 
æ 

Command and Response #rs-232 #rs232
ç <serial_port>.DataBits
æ <serial_port>.DataBits=<databits>
Parameters

Parameter
description
Parameter values
<serial_port> Serial port
number
P1-P2*
<databits> DataBits value 8
9
*The UCX-2x1-HC30 model has one serial port (P1).
Example
ç 
æ 
Parity Setting
Command and Response #rs-232 #rs232
ç <serial_port>.Parity=<parity>
æ <serial_port>.Parity=<parity>
Parameters

Parameter
description
Parameter values
<serial_port> Serial port
number
P1-P2*
<parity> Parity value None
Odd
Even
*The UCX-2x1-HC30 model has one serial port (P1).
Example
ç 
æ 




