 UCX series – User's Manual 82

Video Port Settings - USB-C Related Commands
Restart Link Training
This method is equal with pulling out and plug in again the USB-C connector.
Request and Response #linktraining
ɯ  <ip><in>
INFO:  
ɮ header: 200 OK
Example
ɯ  
ɮ header: 200 OK
Audio Port Settings
Switch Audio Input
Request and Response
ɯ  <ip>
ɯ body: <audio_in>:O3·
ɮ header: 200 OK
ɮ body: <audio_in>:O3
Parameters
Parameter Parameter description  
<audio_in> Audio input port
I1-I4
Audio input port number
Example
ɯ  
ɯ body: I2:O3
ɮ header: 200 OK
ɮ body: I2:O3
INFO:  
output.
ATTENTION!  
the video crosspoint has a limitation: I1 and I5 ports are not available at the same time, only one of them can
be selected to any output. For more details about it see the port diagram in Audio Interface section.

Request and Response
ɯ  <ip>
ɮ header: 200·OK
ɮ body: <audio_in>
Parameters
Parameter Parameter description  
<audio_in> Audio input port
I1-I4
Audio input port number
Example
ɯ  
ɮ header: 200 OK
ɮ body: I2

Request and Response
ɯ  <ip><audio_in>
ɮ header: 200·OK
ɮ body: <audio_out>
Parameters
Parameter Parameter description  
<audio_in> Audio input port
I1-I4
Audio input port number
<audio_out> Audio output port
O3
Audio output port number
Example
ɯ  
ɮ header: 200 OK
ɮ body: O3




