5. Device Concept UCX series – User's Manual 44
Taurus as a Controller Concept
Userscript feature supports the automatism in UCX series devices. The Userscript can be upload and run
in Settings Menu, System
Security: Userscript does not need Serial over IP when it sends serial messages from the UCX to the controlled
device (e.g. projector) via serial port, only the secure ports remain enabled.
GPIO Interface
controllable device and the switcher by the 8-pole Phoenix connector. The direction of the six pin is
GPIO Options - Example #new
Ceiling lamp is turned off by Relay 1 and projection screen is rolled down by Relay 2. Both relays are controlled
by the GPIO port.
send signal to Relay 1 to open which results turning off the lights. Furthermore, GPIO pins also send signal
on the HDMI input, so GPIO pins send signal to Relay 1 to close which results turning on the lights and sends
signal to Relay 2 to open so projection screen returns to its enclosure.
Userscript feature supports the automatism in UCX series devices. The Userscript can be upload and run
in Settings Menu, System
Security: Userscript does not need to use the unsecured ports for GPIO management.
ATTENTION! Please always check the electrical parameters of the devices what you want to control. The
maximum current of one GPIO pin is 30 mA, the maximum total current for the six pins is 180 mA.
OCS Interface
OCS Application Example #new
lamp.
Userscript feature supports the automatism in UCX series devices. The Userscript can be upload and run
in Settings Menu, System
Security: Userscript does not need to use the unsecured ports for OCS management.
) supply a 1 kOhm
external resistor between the 1st and the 3rd pins is necessary.
Further Built-in Features
then copy those settings to the others, thus saving time and resources.
Image and UserScript will be saved.
enabled.
See more information about the settings in the section.
USB-C HDMI
ETHERNET 3
USB-B
IN 1 IN 2 IN 3 IN 4
HDMIUSB-BUSB-C
AUDIO
OUT
OUT 2OUT 1
VIDEO
SERVICE
USB
CONTROL
INPUT SELECT
USB-C HDMI
ETHERNET 3
USB-B
IN 1 IN 2 IN 3 IN 4
HDMIUSB-BUSB-C
AUDIO
OUT
OUT 2OUT 1
VIDEO
SERVICE
USB
CONTROL
INPUT SELECT
USB-C HDMI
ETHERNET 3
USB-B
IN 1 IN 2 IN 3 IN 4
HDMIUSB-BUSB-C
AUDIO
OUT
OUT 2OUT 1
VIDEO
SERVICE
USB
CONTROL
INPUT SELECT
