Linak CO61 User Manual

Page 51 of 295
Standard Integrated Control
23XXXXXX5XXXXXX
Integrated Control with Hall Potentiometer position feedback
23XXXXXX6XXXXXX
Integrated Control with Hall PWM position feedback
23XXXXXX7XXXXXX
LA23 with integrated control is not approved according to IEC60601-1:2005 3
rd
ed., ANSI / AAMI ES60601-1:2005, 3
rd
edition.
Drawing no.: 0239010-A
Hall PWM position feedback
23XXXXXX3XXXXXX
}
}
10 poles connector
10 poles connector
Note: Connection colours only fit with “open-end” cables.
M
_
M+
PWM
VCC +
GND
_
BLUE
BLACK
BROWN
VIOLET
WHITE
BLUE
YELLOW
BROWN
RED
BLACK
INWARDS
OUTWARDS
ENDSTOP IN
ENDSTOP OUT
FEEDBACK
SIGNAL GND
GREEN
VIOLET
WHITE
POWER
INPUT
OUTPUT
