20
3. USB Connector
Connect the USB Connector to the TD3 system via the motor cable. Before use
the system must be confi gured via the TD3 confi gurator to be able to handle the
mounted USB unit. The TD3 confi gurator is a PC software program.
Via this unit you can connect a range of different accessories and gadgets with
a USB plug, just as long as the device works in accordance with the general USB
charger standard (max. 5V and supply max. 0.5A).
Example of a USB unit could be an energy saving busbar to which a standard
lamp can be connected. The lamp can then be turned on and off via the
handset, see example below.
Mounting of the accessories:
All 3 types can either be mounted on the bed using screws OR simply slide the
unit(s) on the groove on the TD3. The mounting screws must be fastened with a
max. torque of 1 Nm.
For mounting on the bedframe: use wood screws (M4) with a maximum head
diameter of 8 mm, and a suitable length.
If several units are used in a system they can be stacked/mounted on top of each
other, taking up a minimum of space.
