13
3.4 Operating Mode
The Flow and Pressure Meter PC 410 is a high precision mul-
timeter for the measurement of differential pressure, volume
flow and temperature as well as the registration of humidity
and ambient pressure. (These two functions are only available
in the version AF). Because of its extremely high precision,
the meter measures even very small pressures. Therefore, it is
ideal to determinate air speed, gas pressure, volume, tension
and also the flue gas temperature. A maximum measuring
range up to 100 hPa and a burst pressure of 0.75 bar provide
a sufficient degree of security even for high pressure ranges.
3.5 Display and key setup
1. The PC 410 has a color 2.4' display.
2. The OLED-technology allows reading the display from
almost any angle of view.
3. Four keys are available below the display to operate the
PC 410.
Fig. 7: Display and keys
Escape On/Off
Scroll/Zoom
To Next Page
