5 Servicing
Inspection and maintenance as required
e3861320
¾ Park truck safely.
¾ Fully lower fork carriage.
¾ Tilt lift mast forwards.
The fork arms must touch the ground.
¾ Apply the parking brake.
¾ Switch off the key switch.
¾ Press the emergency cut-off knob.
¾ Move the steering wheel (2) to the top posi-
tion.
¾ Move the armrest (3) to neutral.
¾ Move the driver’s seat (4) towards the steer-
ing wheel.
e3861352
234
56
1
¾ Operate the locking lever (1) and move the
battery cover (5) back together with the
driver’s seat (4).
CAUTION
If special equipment consisting of the driver cabin
with rear window is involved, the following is neces-
sary before the battery cover can be flapped back:
move in the backrest of the driver’s seat, slide the
driver’s seat towards the steering wheel and raise
the rear window outwards by releasing the locking
devices fitted at the bottom on the right and left .
94 Operating Instructions – 386 807 1001 EN – 03/2006
