Linde E16 - Type Sheet E 20, (Battery 48 V; 6 Pzs; 840 L) Edition 09;2005

6 Technical data
Type sheet E 20, (battery 48 V / 6PzS / 840L) Edition 09/2005
Type sheet E 20, (battery 48 V / 6PzS / 840L) Edition 09/2005
1 Identification
1.1
Manufacturer (abbreviation)
Linde
1.2
Type designation of manufacturer
E20P
1.3
Drive electric, diesel, petrol, gas, mains electric
Electric
1.4
Operation manual, go, stand, sit, commissioner
Sit
1.5
Capacity / Load Q[kg]
2000
1.6
Centre of gravity c [mm]
500
1.8 Load distance
x [mm]
374
1.9 Wheel base
y [mm]
1589
2 Weight
2.1
Own weight
kg
3514
2.2
Axis load with load front / rear
kg
4909 / 605
2.3
Axis load without load front / rear
kg
1809 / 1705
3 Wheels, tyres
3.1
Tyres solid rubber, SE, air, polyurethane
SE
3.2
Tyre size, front
200 / 50 - 10
3.3
Tyre size, rear
16 x 6 - 8
3.5
Wheels, number front/rear (x = driven)
2x/2
3.6 Front tread
b10 [mm]
965
3.7 Rear tread
b11 [mm]
807
4 Tilt lift mast/fork carriage, forward/reverse
4.1
Tiltliftmast/forkcarriage,forward/reverse α/β (°)
5.0 / 7.5
4.2
Height lift mast retracted h1 [mm]
2244
4.3 Free stroke
h2 [mm]
150
4.4
Lift
h3 [mm]
3240
4.5
Height lift mast extended h4 [mm]
3841
4.7
Height above protective roof (cab) h6 [mm]
2130
4.8
Sitting height / standing height h7 [mm]
1065
4.12
Coupling height h10 [mm]
602
188 Operating Instructions – 386 807 1001 EN – 03/2006
