LINET Sprint 200

D9U001ES2-0101_02 13
1.8 Acoustic signalisation (only Sprint 200 with i-Drive Power)
SOUND MEANING
REPEATED BEEP: 0,125s sound / 0,125s silence Fault Notication (Overload)
1.9 Denitions
Adult Patient having a physical size equal to or more than 146 cm, a
mass equal to or more than 40 kg and a body mass index (BMI)
equal to or more than 17 (according to IEC 60601-2-52).
Basic Stretcher Conguration The pricelist model conguration, not including a mattress.
Clearance of Undercarriage The height from the oor to the lowest point of the undercarriage
between the castors, for the manipulation of accessories under a
braked stretcher in the standard position.
Maximum Mass of Mobile Hospital Bed Sum of Empty Stretcher Maximum Mass and Safe Working Load.
Reference number Reference number depends on conguration.
Safe Working Load The highest allowable load on the stretcher (patient, mattress,
accessories and the load supported by those accessories).
Siderail Height The height of the upper crossbar or the edges of the siderails (not
the highest point of the siderail controls) from the patient surface.
Standard Stretcher Position - The height of the mattress support platform with regard to the
oor is 56,5 cm (2-part Mattress Support Platform) or 55,5 cm (4-
part Mattress Support Platform)
- The Mattress Support Platform, including the individual parts, has
to be in a horizontal (level - 0°) position.
- The siderails are always locked in the upper position.
Stretcher Weight The value depends on the product conguration, accessories or
customer adjustments.
Type B Applied Parts The degree of protection against electric shock regarding the
product parts in contact with patient.
