Error/Fault Cause Solution
Faulty Mattress Support Platform Height
Adjustment
Obstacle on the undercarriage cover. Remove the obstacle.
Obstacle under the pedals. Remove the obstacle.
Faulty pedal. Notify the manufacturer´s service
department.
Lowering Backrest from the upright position
not possible
Obstacle under the Backrest or in the drive
mechanism.
Remove the obstacle.
Backrest Release Handle is defective. Notify the manufacturer´s service
department.
Adjusting Siderails not possible Obstacle in the Siderail Release Mechanism. Remove the obstacle.
Siderail Release Mechanism is defective. Notify the manufacturer´s service
department.
Faulty brakes Obstacle blocking brakes mechanically. Remove the obstacle.
The brake mechanism is defective. Notify the manufacturer´s service
department.
18 Troubleshooting (Sprint 200 with i-Drive Power)
