CHAPTER 3C ENGINE 100/125/150/200 SERVICE MANUAL09.0
CHAPTER 3C ENGINE PAGE.3C - 31 -
3.6 TIGHTENING TORQUES OF ENGINE MAIN FASTENERS
Description Thread size Tightening torque (Nm)
Cylinder head bolt M6 9
Oil filter screen cover bolt M30 15
Exhaust pipe nut M6 9
Camshaft seat nut M8 20
Valve adjuster locknut M5 9
Cam chain tensioner bolt M6 10
Transmission case drain bolt M8 19
Clutch drive plate nut M12 55
Clutch driven disk nut M12 55
Starter clutch nut M12 55
Spark plug M10 12
Driven clutch woodruff key nut M22 45
Case (right & left) and case cover (right & left) M16 9
