CHAPTER 3A
ENGINE
260/
300
/
400
cc
A
TV
SERVICE
MANUAL09.0
CHAPTER
3
ENGINE P
AGE.
3A-
41
3.7V
-BEL
T
,CLUTCH AND
SECONDAR
Y/PRIMAR
Y
SHEA
VE
CRANKCASE COVER (LEFT)
Order
Job name / Part name
Q ’ty
Remarks
Crankcase cover (left)
removal
Remove the p
arts in order
.
1
Crankcase cover (left)
1
2
1
3
Hose clam
p B
1
4 Joint
B
1
5 Air
strainer
B
1
6 Hose
clamp
A
1
7 Joint
A
1
8
Air strainer
A
1
Reverse the removal
procedure for installation .
79
81
