Linksys E3000 Chapter 2: Cisco Connect
9
High Performance Wireless-N Router
Restrict Internet Access List
Parental Controls
Add If you want to apply parental controls to additional
computers, click Add.
If you clicked Add, the Set up parental controls for screen
appears.
Set Up Parental Controls For
Select the computer whose parental controls you want
to set up. Then click OK.
Remove If there is a computer that should not have
parental controls applied, select the computer and click
Remove.
Rename To give a computer a new name, select the
computer and click Rename.
If you clicked Rename, the Rename the device screen
appears.
Rename the Device
Enter the new name. Then click Rename.
Set Up Parental Controls
To set up parental controls for a computer, follow these
instructions:
1. Select the computer from the Restrict Internet access on
list. (If the computer is not listed, click Add to select
the computer.)
Parental Controls
2. The Block Internet access option offers the following:
Always To always block Internet access, select this
option.
Specific times To block Internet access during
specific days and times, select this option and set the
schedule:
School nights Select the appropriate start and
end times.
Weekends Select the appropriate start and
end times
Never To always allow Internet access, keep the
default, Never.
3. For the Block specific sites option, click Edit to create a
list of websites you want to block. The default is None.
If you clicked Edit, the Block these sites screen appears.
Block These Sites
a. Enter a website address on each line.
b. Click Save to save your settings.
4. On the Parental controls screen, click Finish to save
your settings.

Table of Contents

Other manuals for Linksys E3000

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Linksys E3000 and is the answer not in the manual?

Linksys E3000 Specifications

General IconGeneral
Ethernet LANYes
Networking standardsIEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Bandwidth2.4 GHz
CompatibilityMac PC
Input current2 A
Input voltage12 V
xDSL connectionNo
Dimensions (WxDxH)225 x 180 x 35 mm
USB ports quantity1
Minimum system requirementsInternet Explorer 6, Safari 3, Firefox 2 Wireless Network-Enabled
Compatible operating systemsWindows XP SP3, Windows Vista SP1, Windows 7 Mac OS X Tiger 10.4.11, Leopard 10.5.8, Snow Leopard 10.6.1
WLAN data transfer rates supported300 Mbit/s
DHCP client-
Antennas quantity3
Ethernet LAN (RJ-45) ports4
Security algorithms128-bit WEP, WPA, WPA2
Bundled softwareSetup Software User Guide
CertificationFCC, IC, CE, Wi-Fi A/B/G/N
Product colorBlack, Blue
LED indicatorsPower, USB, Internet, Wireless, Wi-Fi Protected Setup, Ethernet (1-4)
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Weight and Dimensions IconWeight and Dimensions
Weight452 g
