LION SG1000 User Manual

SG1000
™
SMOKE GENERATOR
12
WWW.LIONPROTECTS.COM
4.2 DISCONNECTING THE BASE
Remove the base by lifting the lever on the bottom front of the base (see Figure 8).
Lift the handle to the horizontal position. This will force the Smoke Generator apart
from the base (see Figure 9).
Lift the Smoke Generator away from the base and slide it back to disengage the
Smoke Generator from the base (see Figure 10).
FIGURE 10: LIFT AWAY FROM THE SG1000 BASE
FIGURE 8: LIFTING THE LEVER
FIGURE 9: LIFT HANDLE TO FORCE SG1000
™
APART
