4.20 BURST MODE SELECTION
Switches 1 through 8 can be turned on for the SG1000
™
Smoke Generator to be controlled by that corresponding
button on the remote.
Group Mode will override Burst Mode, so make sure you
do not have a conict when selecting the modes.
4.21 REPLACING THE BATTERY IN THE WIRELESS REMOTE
If the range of the wireless remote control is greatly decreased, the battery should
be replaced. To replace the battery:
• Remove the battery cover (ITEM 4 in the gure below) using a at screwdriver
in the location shown (ITEM 5 in the gure below).
• Remove the battery (CR2032) from
the holder and insert a new battery.
1 BELT CLIP
2 BLUE INDICATOR
3 CREATE BUTTON
4 BATTERY COVER
5 OPENING POSITION
FOR BATTERY COVER
Note the polarity of the battery.
Insert the new battery with the
“+” visible to the user.
